Vinyl Works 24" Gated Entry A/G Pool Ladder, Taupe | AF-T

The model AF is a double step entry system for easy climbing in and out of your pool. It has a self-closing, self-latching & lockable gate for both safety & to meet code requirements. It is adjustable from 48″ to 56″ with a 12″ top rail clearance. With only a 22” foot print, this ladder allows for maximum use of your pool. This comes in the Taupe (light grey color), AF-T.

Features and Benefits:

• Double step entry for easy climbing
• Self-closing, self-latching & lockable gate for safety & to meet code requirements
• Adjustable from 48" to 56" with 12" top rail clearance
• Minimal obstruction in pool - unit occupies only 22"
• Optional 12 volt in-pool light available (direct from Vinyl Works, here)
• Double, extended handrails on both sides for ease of climbing
• Pool ladder side is weighted with clean gravel (not included).

Manufacturer Specifications

• VINYL WORKS CANADA manufactures this Step System to meet or exceed the most current / active ANSI/APSP/ICCISPSC code requirements for entry systems, in-pool steps, ladders and ladder enclosures
• The Model AF Step Entry System is manufactured using maintenance free resins to maintain strength & color. Stainless
  hardware is used for years of worry free & safe use
• The system is designed for a 300 lb. capacity (one person only). It is a stable entry system; ideal for everyday use and
  easier to climb as compared to a conventional a-frame pool ladder (flat bottom pools only)
• The Step Entry System is packaged in one convenient carton and can ship by courier
• The Model AF includes a full gate system to meet or exceed all code requirements for enclosures. The gate opens outward and is self-closing, self-latching and lockable (lock not included). The gate latch measures 55 inches from ground surface, exceeding requirements. The gate is manufactured with a solid design and is non-climbable. The exterior portion of the unit is entirely enclosed for protection when the pool is not in use.
• The system utilizes double handrails for both the in pool and exterior portions for greater safety and ease of entering & exiting the pool. Handrails are accessible from all treads & top platform. Clearance between handrails is 20.25"
• All treads measure 7.5" x 20". This makes the system very easy to climb when entering and exiting the pool
• The system is extremely easy to assemble, most of the components simply snap and lock together
• The top platform spans 12" deep x 20.25" wide (inside handrails) to protect the top rail of the pool and allows for easy entry & exit of the pool. The top platform adjusts up & down to accommodate any pool wall height from 47.5" minimum
  to 56.25" maximum
• Minimum obstruction of swimming space ~ unit occupies only 22" within the pool (ideal for smaller pools)
• Smoothly rounded base allows in pool portion of stair to be stable and not damage the pool liner. A ladder or stair pad can be used for additional protection if desired (recommended & sold separately)
• The in-pool portion of the system is designed to prevent entrapment while allowing great circulation of the pool water
  (both through the side frames and through the tread risers)
• All stair treads and top platform have been designed with a ridged, non-slip surface for safe use
• The step risers are embossed with no diving and no jumping signs for safety reminder. As well, the entry contains all required safety signage (embossed directly into the face of the gate at entry)
• An optional IN-POOL LIGHT is available for use with this entry (Model OPT12V). The 12-volt light is packaged and sold separately. It includes interchangeable colored lenses, a 10ft cable and UL listed transformer.  Poolaroo does not presently stock this item, but is available direct from manufacturer, here.
• The Model AF Step Entry System can be used with our Pool Fence Systems to totally enclose and protect your pool.
• Both our 24" and 36" fencing will connect to the entry system by using our Connector Kits (sold separately)
• Each unit includes explicit installation & safety instructions and all necessary hardware (lock excluded) for proper, safe and normal assembly and use. Never deviate from these instructions


Also known as: AFT
