The Hayward Super Pump High Efficiency Pump (W3SP2607X10) delivers dependable, efficient circulation for in-ground pools, backed by the heavy-duty motor and field-proven design that have made the Super Pump a mainstay for aftermarket and new installations alike.
IMPORTANT: DUAL-VOLTAGE CONFIGURATION
This pump is field-configurable for 208-230V or 115V (60 Hz) supply. Voltage selection and wiring must be performed by a qualified electrician in accordance with the National Electrical Code.
Unique Features & Technology
-
Heavy-duty, high-performance motor with an open drip-proof (ODP) design suited for continuous pool circulation duty.
-
Tool-free maintenance via exclusive swing-away hand knobs on the strainer cover — no tools, clamps, or loose parts required.
-
110-cubic-inch strainer basket with load-extender ribbing for extra leaf-holding capacity and free-flowing operation.
-
See-through strainer cover lets you check basket condition at a glance, without opening the housing.
- Rated WEF 3.4 and DOE Compliant, reflecting Hayward's efficiency standards for this class of pump.
Specifications
| Hayward Model |
W3SP2607X10 |
| Total HP |
1.1 HP |
| Motor Type |
ODP |
| Number of Speeds |
Single Speed |
| Voltage at 60 Hz |
208-230/115 |
| Phase |
Single Phase |
| WEF |
3.4 |
| DOE Compliant |
Yes |
| Pool Type |
In Ground |
| Warranty - Parts |
1-year |
Pool Size & Application
Designed for in-ground pool circulation, the Super Pump High Efficiency Pump is built for both new installations and pump replacements, offering the reliability Hayward positions as its standard for aftermarket service work.
System Integration
As with all pool circulation pumps, this unit must be installed on a dedicated, properly protected electrical circuit by a qualified electrician, with GFCI protection as required by code. Consult manufacturer specifications for automation/control system compatibility.
Common Replacement Parts
Keep this pump running with genuine Hayward wear parts: Super Pump Strainer Basket (SPX1600M), Strainer Cover (SPX1600D), Cover Gasket (SPX1600S), Shaft Seal Assembly (SPX1600Z2), Impeller for this pump (SPX2607C), and Drain Plug and Gasket (SPX4000FG) — one required per pump.
Poolaroo Pro Tip
Take advantage of the see-through strainer cover to do a quick visual basket check each week during peak swim season — catching leaf buildup early keeps flow steady and reduces strain on the motor. When it's time to clean the basket, the swing-away hand knobs let you open the cover by hand, with no tools needed.
